BELARUS-920.4/952.4 Operating manual
51
Table A.1, continued
Designation Name Qty. Note
Р2 Instrument clusters (KP-5) with CAN 1 For 920.4/950.4
Instrument clusters (KP-6) with CAN 1 For Belarus-1025.4/1221A
QS1 Remote battery switch 24V 1
R1 Ballast resistor 1
R2 Generator ballast resistor (CAN) 1
SA1 Roadtrain sign lamp switch 1
SA2, SA3 Headlight switch 2
SA4 Fan heater switch 1
SA5 Windshield wiper switch 1
SA6 Starter and instrument switch 1 COBO, Italy
SA7 Understeering combined switch 1
SA8 Battery switch 1
SA9 Windshield washer switch 1
SA10 Central light switch 1
SA11 Start lock switch ВK12-41 1 For 1025.4/1221.4
Start lock switch ВK 2-41 1 For 920.4/950.4/1021.4
SA12 Flashing beacon switch 1
SB1 Emergency stop signaling switch 1
SB2 Brake light switch 1
SB3 Park brake light switch 1
SP1 Air filter clogging sensor 1
SP2 HSU emergency oil pressure sensor 1
SP3 Pneumatic system emergency air pres-
sure indicator
1
UZ1 Voltage converter 1
ХР1.1, ХР116 Single-pin terminal block 16
ХР2.1…ХР2.7 Two-pin terminal block 7
XP4.1, XP4.2 Four-pin terminal block 2
ХР6.1 Six-pin terminal block 1
XS1.1…
XS1.20
Single-pin female receptacle 20
XS2.1…XS2.4, XS2.6…XS2.
18
Two-pin female receptacle 18
XS3.1, XS3.2, XS3.4 Three-pin female receptacle 3
XS4.1 Four-pin female receptacle 1
XS5.1, XSS.2,
XS5.5…XS2.10
Five-pin female receptacle for relay
switch
9
