Bell'O TPC2133 - Page 10

Fig. 2-4
M4
M4
M3
M2
M2
M13
2-8. With the help of an assistant, carefully PLACE the Post of the Swivel Bar (M4) down into the tube in the Mounting
Bracket (M3), and SECURE with the Post Locking Clip (M13) as shown.
SKIP TO PAGE 20 FOR GLASS SHELF INSTALLATION INSTRUCTIONS.
