Belling G755 - Page 6

6
A Rp
1
/
2
union is fitted to the cooker. Connection to the appliance should be made
with an approved appliance flexible connection to BS669. The length of the hose
should be such that when the cooker is in situ, it does not touch the floor.
Stability Chain The cooker must be secured by a security chain to the wall or partition behind the
cooker. (Fig.4)
Fig. 1 Fig. 2
Fig.3 Fig.4
C
D
A
E
B
A=150
B=175
C=700
D=500
E=150
