USING THE HOB (13 AMP VERSIONS)
13 AMP OPERATION
Your hob has been designed to allow you to connect to a 13Amp fused spur and is
suitable for a variety of installations not possible with conventional electric hobs, such
as direct replacement for a gas hob without the need to install a 32 Amp cooker socket,
thus eliminating the need for an expensive rewire of the kitchen.
How it works
Each time you operate the hob, the total power level of the hob is calculated.
If the total power requested reaches 2.8 kW the energy management system warns
you that the limit is reached. Signalled by a letter “r” in the zone window (Lasts for 3
seconds ) and an audible “Beep”. The hob cook zones can be used in any combination
or setting until the 2.8 kW power setting is reached. (See Tables Below)
Any further power increase is not allowed!
To use any new zones requires you to reduce the power of one of the other selected
cook zones.
13 Amp Supply Power Setting Examples
Set Cook Zone Examples Of Possible Power Setting Combinations
Left Hand Front 9 6 1 6 Off
Left Hand Rear 9 6 3 Off P
Right Hand Front 1 5 4 4 9
Right Hand Rear Off 5 P 9 Off
“13 Amp Supply” Power Management Check
Set Cook Zone Correct Power Setting Check “13 Amp Supply”
Left Hand Front 9
Left Hand Rear 9
Right Hand Front 1
Right Hand Rear “r” and warning “Beep” when zone is activated
Warning! If you can set a power level on the right hand cook zone when the
other zones are set as above. Please switch off and contact customer service for
advice.
