Benchmark Games Ticket Station - Page 43

Connector/
Pin
Device/ Signal
Type/
Color
To/
From
To/
From
To/
From
To/
From
To/
From
To/
From
To/
From
To/
From
Comments
C1:
Door to Main HNS
connector
Mini F
Pin 1
Printer GND
Black
C6:P2
Pin 2
Main Controller
GND
Black
C2:P8
Pin 3
Ground
Black
C19:P1
C18:P1
C16:P1
C17:P1
C11:P1
C5:P3
C7:P3
Pin 4
RS 485 B
Gray
C4:P1
C5:P2
C7:P2
Is a twisted Pair with
Pin 9
Pin 5
RGB Sync Input
Blue/Org
C2:P4
Pin 6
Printer Power 12V
Yellow
C6:P1
Pin 7
Main Controller
Power 12V
Yellow
C2:P9
Pin 8
12V Power
Yellow
C19:P3
C18:P3
C14:P1
C15:P1
C16:P3
C17:P3
C9:P1
C5:P4
C7:P4
Pin 9
RS 485 A
Blue
C4:P2
C5:P1
C7:P1
Is a twisted Pair with
Pin 4
Pin 10
RGB Sync Output
Blue/Red
C3:Pp
C2:
Main Controller
Board (P5) Input
Mini F
Pin 1
Ticket Scanner 2
Green/Wht
C14:P2
Pin 2
Ticket Scanner 1
Green/Blk
C14:P3
Pin 3
Pin 4
RGB Sync Input
Blue/Org
C1:P5
Pin 5
Hall Effect Sensor
Blue/Gry
C13:P2
Pin 6
Ticket Reader GND
Black
C15:P4
C14:P4
C13:P3
Pin 7
Hall Effect Sensor
Power 5V
Yellow
C13:P1
Pin 8
Main Controller
GND
Black
C1:P2
Pin 9
Main Controller
Power 12V
Yellow
C1:P7
