Pin 10
Switch Receipt
Buton
Purple/Wh
t
C12:P1
Pin 11
Opto Ticket Notch
Purple/Blk
C18:P2
Ticket Count
Pin 12
Opto Ticket Insert
(motor)
Blue/Blk
C19:P2
signal needed to turn
on motor
Pin 13
Ticket Scanner 4
Green/Org
C15:P2
Pin 14
Pin 15
Ticket Scanner 3
Green/Red
C15:P3
Pin 16
C3:
Main Controller
Board (P11)
Outout
Mini F
Pin 1
Stepper Red
White/Red
C8:P4
Pin 2
Stepper Black
White/Blk
C8:P3
Pin 3
RGB Sync Out
Blue/Red
C1:P10
Pin 4
Pin 5
Button LED
Black/Wht
C10:P1
Pin 6
Pin 7
Pin 8
Pin 9
Stepper Blue
White/Blu
C8:P2
Pin 10
Stepper Green
White/Grn
C8:P1
Pin 11
Pin 12
Pin 13
Pin 14
Pin 15
Pin 16
C4:
Main Controller RS
485 (P6)
Micro F
Pin 1
RS 485 B
Gray
C1:P4
C5:P2
C7:P2
Pin 2
RS 485 A
Blue
C1:P9
C5:P1
C7:P1
C5:
OLED Display
Mini F
