Benchmark Games Ticket Station - Page 45

Pin 1
RS 485 A
Blue
C1:P4
C4:P2
C7:P1
Is a twisted Pair with
Pin 2
Pin 2
RS 485 B
Gray
C1:P9
C4:P1
C7:P2
Is a twisted Pair with
Pin 1
Pin 3
Ground
Black
C1:P3
C19:P1
C18:P1
C16:P1
C17:P1
C11:P1
C7:P3
Pin 4
12 V Power
Yellow
C1:P8
C19:P3
C18:P3
C14:P1
C15:P1
C16:P3
C17:P3
C9:P1
C7:P4
C6:
Printer Power
Pin 1
12V Power
Yelow
C1:P6
Pin 2
Ground
Black
C1:P1
Pin 3
Pin 4
C7:
5 Didit Display
Micro F
Pin 1
RS 485 A
Blue
C1:P4
C4:P2
C5:P1
Is a twisted Pair with
Pin 2
Pin 2
RS 485 B
Gray
C1:P9
C4:P1
C5:P2
Is a twisted Pair with
Pin 1
Pin 3
Ground
Black
C1:P3
C19:P1
C18:P1
C16:P1
C17:P1
C11:P1
C5:P3
Pin 4
12V Power
Yellow
C1:P8
C19:P3
C18:P3
C14:P1
C15:P1
C16:P3
C17:P3
C9:P1
C5:P4
C8:
Stepper Motor
Micro F
Pin 1
Stepper Green
White/Grn
C3:P10
Pin 2
Stepper Blue
White/Blu
C3:P9
Pin 3
Stepper Black
White/Blk
C3:P2
Pin 4
Stepper Red
White/Red
C3:P1
C9:
Button Power
Pin 1
12 V Power
Yellow
C1:P8
C19:P3
C18:P3
C15:P1
C16:P3
C17:P3
C5:P4
C7:P4
C10:
Button LED
Pin 1
Signal
Black/Wht
C3:P5
C11:
Button Ground
Pin 1
Ground
Black
C1:P3
C19:P1
C18:P1
C16:P1
C17:P1
C5:P3
C7:P3
C12:
Button Switch
Pin 1
Switch Signal
Purple/Wh
t
C2:P10
