C13:
Hall Effect Sensor
Micro F
Pin 1
Power 5V
Red
C2:P7
Pin 2
Signal
Blue/Gry
C2:P5
Pin 3
Ground
Black
C2:P6
C15:P4
C14:P4
C14:
Ticket Scanner 1/2
Micro F
Pin 1
12V Power
Yellow
C1:P8
C19:P3
C18:P3
C15:P1
C16:P3
C17:P3
C9:P1
C5:P4
C7:P4
Pin 2
Ticket Scanner 2
Green/Wht
C2:P1
Pin 3
Ticket Scanner 1
Green/Blk
C2:P2
Pin 4
Ground
Black
C2:P6
C15:P4
C13:P3
C15:
Ticket Scanner 3/4
Micro F
Pin 1
12V Power
Yellow
C1:P8
C19:P3
C18:P3
C14:P1
C16:P3
C17:P3
C9:P1
C5:P4
C7:P4
Pin 2
Ticket Scanner 4
Green/Org
Pin 3
Ticket Scanner 3
Green/Red
Pin 4
Ground
Black
C2:P6
C14:P4
C13:P3
C16:
Opto Transmitter
Micro F
Pin 1
Ground
Black
C1:P3
C19:P1
C18:P1
C17:P1
C11:P1
C5:P3
C7:P3
Pin 2
Pin 3
12V Power
Yellow
C1:P8
C19:P3
C18:P3
C14:P1
C15:P1
C17:P3
C9:P1
C5:P4
C7:P4
C17:
Opto Transmitter
Micro F
Pin 1
Ground
Black
C1:P3
C19:P1
C18:P1
C16:P1
C11:P1
C5:P3
C7:P3
Pin 2
Pin 3
12V Power
Yellow
C1:P8
C19:P3
C18:P3
C14:P1
C15:P1
C16:P3
C9:P1
C5:P4
C7:P4
C18:
Ticket Count Optic
Micro F
Pin 1
Ground
Black
C1:P3
C19:P1
C16:P1
C17:P1
C11:P1
C5:P3
C7:P3
Pin 2
Signal
Purple/Blk
C2:P11
Pin 3
12V Power
Yellow
C1:P8
C19:P3
C14:P1
C15:P1
C16:P3
C17:P3
C9:P1
C5:P4
C7:P4
C19:
Ticket Insert Optic
(Motor)
Micro F
Pin 1
Ground
Black
C1:P3
C18:P1
C16:P1
C17:P1
C11:P1
C5:P3
C7:P3
Pin 2
Signal
Blue/Blk
C2:P12
Pin 3
12V Power
Yellow
C1:P8
C18:P3
C14:P1
C15:P1
C16:P3
C17:P3
C9:P1
C5:P4
C7:P4
C20:
Speaker
