18
3. Lift the cutting depth locking lever upward to allow the blade to rise above the
bottom of the sole plate so the blade will NOT contact the workpiece (Fig. 4).
Do NOT lock the cutting depth locking lever.
4. Set the saw on the workpiece (1) so the sole plate is flat on the workpiece.
(Fig. 11).
5. Open the blade guard by rotating the blade guard lever (2) forward.
6. Align the saw blade with the cutting line (3) using the 0° cutting mark on the
sole plate.
NOTE: Make sure the saw blade is inside the area to be cut out.
7. Start the saw and slo
wly lower the blade onto the workpiece while holding the
blade guard lever forward to allow the blade to cut into the workpiece (Fig. 12).
Allow the blade to cut through the wood.
8. Continue lowering the blade into the workpiece until the full cutting depth has
been achieved. Continue sawing toward the cutting line and complete the cut as
required.
1 2 3
FIG. 11 FIG. 12
MAINTENANCE
WARNING: When servicing, use only identical replacement parts. The use of
any other part may create a hazard or cause product damage.
DO NOT use solvents when cleaning plastic parts. Plastics are susceptible to
damage from various types of commercial solvents and may be damaged by their
use. Use a clean cloth to remove dirt, dust, oil, grease etc.
WARNING: Do not allow brake fluids, gasoline, petroleum-based products,
penetrating oils, etc. to come into contact with plastic parts. They contain
chemicals that can damage, weaken or destroy plastic.
DO NOT abuse power tools. Abusive practices can damage the tool and the
workpiece.
WARNING: DO NOT attempt to modify tools or create accessories. Any such
alteration or modification is misuse and could result in a hazardous condition
leading to possible serious injury. It will also void the warranty.
1265-000
7-1/4" CIRCULAR SAW
