BW SERIES
6.2. USING SPRAY NOZZLES
WARNING!
High pressure in nozzle area. Risk of injury caused by improperly
locked nozzle.
When replacing nozzles with the engine running the trigger
safety lock MUST be engaged.
To connect or disconnect a spray tip pull back on the quick connect collar. Insert
or remove the spray tip then release the collar. Tug on the spray tip to ensure it is
secured. The tips are color coded and stored on the panel.
Nozzle Selection Guide
0° 15° 25° 40° 65°
Paint Stripping
Concrete
Deck
Gutters
Siding
Vehicles
Windows
Furniture
Detergent
