Benchmark BW Series Manual

33
BW SERIES
NOTE
 Oil max. capacity:
 BW3500: 600 mL
 BW3800: 700 mL
 BW4400: 1.1 L
 SAE10W-30 oil is recommended for general use.
 DO NOT OVERFILL.
NOTE
 Do not tilt the pressure washer when adding engine oil. This could result
in overlling and damage to the engine.
 Use high quality engine oil with strong detergents. Using non-detergent
or 2-stroke oil could shorten the engine’s working life.
 Handle and store engine oil with care, avoid getting dirt or dust into the oil.
 Do not mix different engine oils.
 Before the engine oil falls below a safe level, the low oil alert system will
automatically shut off the engine. The low oil light will turn on.
 To avoid the inconvenience of unexpected engine shutoff, check the
engine oil level as often as possible.
Maximum Oil Level
Minimum Oil Level
0°C
10 20 30 40 50-10-20-30
20
32°F
40 60 80 100 120
°C
°F0-20
15W-50
10W-30
Synthetic 5W-30
5W-30
Effective Viscosity Range of Engine Oils
8.6
8.6.2)Ta
aft
8.6.2)Take off the spark arrester
after the engine cool down.
8.6.2)Take off the spark arrester from th e
after the engine cool down.
Maximum Oil Level
Minimum Oil Level
0°C
10 20 30 40 50-10-20-30
20
32°F
40 60 80 100 120
°C
°F0-20
15W-50
10W-30
Synthetic 5W-30
5W-30
Effective Viscosity Range of Engine Oils
8.6
8.6.2)Ta
aft
8.6.2)Take off the spark arrester
after the engine cool down.
8.6.2)Take off the spark arrester from the
after the engine cool down.
