TD-550/560 Oil in Water Analyzer Introduction
PN 106737
REV H
TD-550/560 Oil in Water Analyzer
Operation Manual
5
The TD-550/560 must be operating in the linear range to display accurate results. To determine
whether your calibration standard is in the linear range, rst, select the NUV or DUV channel (TD-560)
and proper cuvette size and calibrate the analyzer with a standard solution of known concentration.
(See Section 3 General Considerations for Analysis for conguration guidelines.) Then prepare a new
standard that is half the concentration of the standard solution by mixing equal volumes of the original
calibration standard and pure blank. Place the diluted standard in a clean cuvette, place the cuvette
in the sample well and tap Read on the Home screen (see Section 2.1 Touch Screen Interface). If the
displayed result is greater than half the original standard concentration, allowing for some error due to
dilution, the analyzer’s calibration is beyond the linear range. The linear range is dependent upon the
sample cuvette size and the optical channel of the analyzer; thus using a smaller cuvette size and/or
changing the optical channel (TD-560) can extend the linear range.
1.3 SPECIFICATIONS
Common Target Oils TD-550: crude oil, some diesels, fuel oils and some lubrication oils
TD-560: all oils listed for the TD-550 plus gas condensates, BTEX, gasoline, sty-
rene, phenol, jet fuel, kerosene, heat transfer uids and hydraulic oils
Detection Range 5 ppb to 5000 ppm (dependent on target oil)
Power External power supply: 90–240 VAC and 6–8 hours on battery
Data Output USB and micro SD card
Calibration Direct and raw
Display Units ppm, ppb, mg/l, ug/l, raw
Approvals CE
Data Logging and Graphing Stores multiple calibrations and site locations
Records each sample analyzed with time stamp, location and results for fast lookup
Sort by date, location or calibration
1.4 REVISION HISTORY
Date Revision Section/Change Description
1 June 2017 A Initial version of operation manual.
12 Dec 2018 B 6 Troubleshooting
Throughout
Additional procedures.
Changes to touch screen software and
interface.
11 March 2020 C 2 Operation Changes to interface description, cuvette
selection and calibration overview sections.
6 Troubleshooting Changes to section on diagnostics screen,
including functionality check procedure.
14 Dec 2020 D Throughout Updated company addreess.
31 Jan 2022 E Section 3.1 Analyzing a
Sample
Updated instructions for proper use
of cuvettes and adapters for sample
measurements.
Section 3.2 General
Information and
Precautions
Updated instructions for proper use
of cuvettes and adapters for sample
measurements.
6 Troubleshooting Updated instructions for proper use
of cuvettes and adapters for sample
measurements.
11 May 2022 F Throughout Updated instructions to reect new tablet
operations.
