11
Ticket Taker
runs slowly
then stops
Hall effect pcb1 output not getting to the ticket eater board.
1. Check that when the motor is running, the LED2 on
the hall effect pcb1 is flashing at least one time per
motor revolution. If the LED does not flash:
a. Check to see if the motor pulley3 is tight on the
motor shaft.
b. Check the distance of the motor pulley from the
hall effect sensor pcb. There is a magnet on
the inside of the motor pulley that activates the
sensor every revolution. If the pulley is located
too far from the sensor pcb, the magnetic
strength will be too weak to activate the sensor.
c. Check voltage to the hall effect pcb
If the LED does flash, check the output of the hall effect
sensor pcb all the way to the ticket eater pcb
