62 Bend-Tech Dragon A150
Troubleshooting Guide
Control Box
13
Tools Required
• Flat blade screwdriver
• Phillips screwdriver (standard)
• Phillips screwdriver (small)
1. Remove the four Motor Cables from the Gecko Drive inputs. Ensure the cables are clearly
marked so they can be reinstalled in their proper locations. Removal of the Motor Cables
2. On the inside of the Control Box, remove the four Phillips head screws that secure the
aluminum plate holding the orange wiring connectors. Ensure no wires come loose from
their respective connectors.
3. Remove the four Phillips head screws at each corner of the Gecko drive. Hold the nuts on
4. With the Gecko Drive free, turn it sideways so it can be pushed through the Control Box
housing and placed out of the way. Ensure no wires come loose from the Gecko Drive.
5. Install the new Gecko Drive using the four Phillips head screws and nuts.
6. Using the small Phillips screwdriver, carefully transfer each wire from the old Gecko Drive
to the corresponding port in the new Gecko Drive.
7. Reinstall the Motor Cables.
