Autostacker™ Parking Lift 23 P/N 5900002 — Rev. D — August 2019
To anchor your Autostacker to the ground:
1. Double check to make sure the Autostacker Bases are where you want them.
Once Anchor Bolts are torqued into position, they are not easily removed.
Make sure the Leg Assemblies are correct before anchoring.
2. Using the holes in the Autostacker Bases as guides, drill the holes 4 inches deep.
Go in straight; do not let the drill wobble.
⚠ CAUTION Do not drill all the way through the Concrete; if you punch completely through the
slab, you could compromise the holding strength of the Anchor Bolt.
Use a carbide bit (conforming to the current ANSI B212.15).
The diameter of the drill bit
must
be the same as the diameter of the Anchor Bolt. So if you are
using a ¾ inch diameter Anchor Bolt, for example, use a ¾ inch diameter drill bit.
3. Clean each hole.
Use a wire brush, vacuum, hand pump, or compressed air.
Do
not
ream the hole. Do
not
make the hole any wider than the drill bit made it.
