Autostacker™ Parking Lift 52 P/N 5900002 — Rev. D — August 2019
Specifications
Control Stand –
Front
of the
Lift
PL-6SR PL-6SRX
A Total width
103" (8.6 feet) / 2,616 mm
111" (9.3 feet) / 2,815 mm
B Platform width 83.75" (7 feet) / 2,127 mm 91.75" (7.7 feet) / 2,331 mm
C Drive-thru width 83" (7 feet) / 2,112 mm 90.75" (7.7 feet) / 2,305 mm
Control Stand –
Rear
of the
Lift
PL-6SR PL-6SRX
A Total width 103" (8.6 feet) / 2,616 mm 111" (9.3 feet) / 2,815 mm
A1 Total width (with Window in
Bottom Connector Tube)
106" (9 feet) / 2695 mm
114" (9.6 feet) / 2,898 mm
B Platform width 83.75" (7 feet) / 2,127 mm 91.75" (7.7 feet) / 2,331 mm
C Drive-thru width 83" (7 feet) / 2,112 mm 90.75" (7.7 feet) / 2,305 mm
Rise/Lower speed 30 seconds
Motor 220 VAC at 60 Hz, 5 HP, 1 Ph
208-230/460 VAC at 50/60 Hz, 10 HP, 3 Ph
*For installations placing the Control Stand at the
Rear
of the Lift, use total width measurement (
A
) for
creating Chalk Line Guides; do not use the A1 measurement.
