HD-9 Series Four-Post Lifts 9 P/N 5900123 — Rev. M — February 2020
Model HD-9ST HD-9STX
Lifting Capacity 9,000 lbs / 4,082 kg
Max capacity at Front Axle 4,500 lbs / 2,041 kg
Max capacity at Rear Axle 4,500 lbs / 2,041 kg
a Min. runway height
5" / 125 mm
b Maximum rise
70" (5.10 feet) / 1,778 mm 82" (6.10 feet) / 2,083 mm
c Maximum lifting height
75" (6.3 feet) / 1,903 mm 87" (7.3 feet) / 2,208 mm
d Overall width
100.25" (8.4 feet) / 2,546 mm
e Outside length
174" (14.6 feet) / 4,420 mm 198" (16.6 feet) / 5,029 mm
f Overall length
200.5" (16.9 feet) / 5,094 mm 224.5" (18.9 feet) / 5,704 mm
g Height of post
88" (7.4 feet) / 2,235 mm 100" (8.4 feet) / 2,540 mm
h Distance between posts
90" (7.6 feet) / 2,292 mm
i Drive-thru clearance
76.5" (6.5 feet) / 1,943 mm
j Runway width
19" / 482 mm
k Runway length
164.5" (13.9 feet) / 4,178 mm 188.5" (15.9 feet) / 4,788 mm
l Width between runways
38" (3.2 feet) / 963 mm
m Runway centerline
56.5" (4.9 feet) / 1,435 mm
n Outside edge of runways
75.5" (6.4 feet) / 1,918 mm
Min. wheelbase @ rated
capacity
1
115" (9.7 feet) / 2,921 mm 135" (11.3 feet) / 3,429 mm
Min. wheelbase @ 75 capacity
1
100" (8.4 feet) / 2,540 mm 115" (9.7 feet) / 2,921 mm
Min. wheelbase @ 50 capacity
1
85" (7.1 feet) / 2,159 mm 95" (7.11 feet) / 2,413 mm
Min. wheelbase @ 25 capacity
1
70" (5.10 feet) / 1,778 mm 80" (6.8 feet) / 2,032 mm
Safety Lock positions 14, spaced every 4" / 102 mm 17, spaced every 4" / 102 mm
Lifting time 45 – 50 seconds
Motor 60 Hz, 1 Ph (special voltages available upon request)
1
The Lift supports less weight than its rated capacity if the Vehicle’s wheelbase is shorter; this is
because the wheels are closer to the middle of the Runways, where there is less strength.
For example, the maximum weight allowed on the Lift for a Vehicle with a wheelbase of 85" is
50 percent of the Lift’s rated capacity (or 4,500 lbs when the rated capacity is 9,000 lbs).
Specifications subject to change without notice .
