10
Fig 3
2. Install the cylinder fittings in cylinder ports
so that each fitting points towards the
entrance side of lift. ( Fig 3 ).
3. At this point install the cylinders into the
carriages. With the post on the ground
slide the carriage towards the top of the post
approximately 6 feet. Insert the casing side
of the cylinder into the entry hole on the bot-
tom of the carriage. Push the cylinder in all
the way until the collar touches on the car-
riage. Slide the carriage all of the way back
down until the cylinder makes contact with
the base plate of the post. (Fig 4).
Fig 4
5. Route both hoses in their respective columns PRIOR to raising columns to their vertical position.
When routing the hydraulic hose through the columns, make sure to route through the retaining
clips welded inside each column. Make sure that the hose is clear of any moving parts. It may be
necessary to tie hose clear by using nylon tie straps or wire.
Important Note
When routing the hydraulic
hose through the columns,
make sure to route through the
retaining clips welded inside
each column.
