IMPORTANT NOTE:
When installing hydraulic fittings
and hoses it is not necessary to
use Teflon tape or other sealant.
Teflon tape and other sealing
compounds can contaminate the
system and cause malfunction-
ing of lift.
ALL WIRING MUST
BE PERFORMED
BY A CERTIFIED
ELECTRICIAN
STEP SEVEN
( Mounting The POWER UNIT )
1. Attach the power unit to the POW-
ERSIDE COLUMN using four M8 hex
bolts and nuts supplied. Fill the reser-
voir with 10 WT. HYDRAULIC OIL OR
DEXRON TYPE III ATF, approximately
four gallons. Make sure the funnel
used to fill the power unit is clean.
2. Remove plug from power unit and
install the 90* fitting w/ O-ring into the
power port on the power unit. (Fig 10)
3. The standard power unit for your lift is
220 volt, 60HZ, single phase. All wiring
must be performed by a certified electri-
cian only. SEE WIRING INSTRUC-
TIONS AFFIXED TO MOTOR FOR
PROPER WIRING INSTRUCTIONS
"DO NOT run power unit with no oil. Damage to pump
can occur.”
"The power unit must be kept dry. Damage to power
unit caused by water or other liquids such as deter-
gents, acid etc., is not covered under warranty.”
"Improper electrical hook-up can damage motor and will
not be covered under warranty.”
"Motor can not run on 50HZ without a physical change
in motor.”
"Use a separate breaker for each power unit.”
"Protect each circuit with time delay fuse or
circuit breaker.”
“For 208-230 volt, single phase, use a 25 amp fuse.”
“For 208-230 volt, three phase, use a 20 amp fuse.”
“For 380-440 volt, three phase, use a 15 amp fuse.
Fig 10
