13
NOTE:
When routing the hydraulic hose through
the columns, make sure to route through
the retaining rings welded inside each col-
umn. Make sure that the hose is clear of
any moving parts. It may be necessary to
tie hose clear by using nylon tie straps or
wire.
STEP NINE
( Installing The HYDRAULIC LINES. )
1. Install the Bulkhead Tee fitting into the
powerside post. The through hole is locat-
ed approximately 90 inches from the floor
on the back wall of the powerside post.
2. Connect the power side cylinder hose
to the the tee fitting Be sure to route the
hose through the retainer rings inside the
columns.
3. Route the offside cylinder hose
(crossover hose) up through the post and
across the top trough, down the post and
connect it to the bulkhead tee fitting.
Fig 18
Fig 18
STEP TEN
( Routing The EQUALIZER CABLES )
1. Raise and lock each carriage approximate-
ly 28” above the ground. See Fig. 19
Make sure that the safety locks on each
column are fully engaged before attempt-
ing to route equalizer cables and/or
hoses. Carriages must be equal height
from the floor before proceeding.
2. With the carriages in equal position from
the floor, route the equalizer cables. If you
have already routed them in the post as stat-
ed in step 3. Remove the pulley and route the
cable around the pulley and reinstall it.
Make sure that the safety
locks on each column are
fully engaged before attempt-
ing to route equalizer cables
and/or hoses. Carriages must
be equal height from the floor
before proceeding
.
