XPR-10 Series Two-Post Lifts 3 P/N 5900951 — Rev. D — May 2019
Table of Contents
Introduction 3 Operation 66
Shipping Information 3 Maintenance 72
Safety Considerations 4 Troubleshooting 74
FAQ 6 Wiring Diagrams 76
Components 7 Labels 77
Specifications 9 Parts Drawings 80
Installation Checklist 14 ALI Store 90
Installation 15 Maintenance Log 91
Introduction
This manual describes these XPR-10 Series Two-Post Lift models:
• XPR-10S. A Two-Post Symmetric Lift that raises Vehicles up to 10,000 pounds (4,536 kg).
Also available with extended height (for taller Vehicles), Low-Pro™ arms, and both.
• XPR-10AS. A Two-Post Asymmetric Lift that raises Vehicles up to 10,000 pounds (4,536 kg).
Also available with extended height (for taller Vehicles), Low-Pro™ arms, and both.
• XPR-10XLS. A Two-Post Symmetric Lift with extended rise under the Vehicle (for taller
mechanics) that raises Vehicles up to 10,000 pounds (4,536 kg).
Also available with extended height (for taller Vehicles), Low-Pro™ arms, and both.
• XPR-10AXLS. A Two-Post Asymmetric Lift with extended rise under the Vehicle (for taller
mechanics) that raises Vehicles up to 10,000 pounds (4,536 kg).
Also available with extended height (for taller Vehicles), Low-Pro™ arms, and both.
All models support Narrow or Wide drive-through configurations; choose the desired width
configuration
before
installation based on your specific space or Vehicle width requirements. All
models have Overhead Assemblies and clear floors. All models are ALI certified.
⚠ DANGER Be very careful when installing, operating, maintaining, or repairing this equipment;
failure to do so could result in property damage, product damage, injury, or (in very
rare cases) death. Make sure only authorized personnel operate this equipment. All
repairs must be performed by an authorized technician. Do not make modifications
to the unit; this voids the warranty and increases the chances of injury or property
damage. Make sure to read and follow the instructions on the labels on the unit.
More information about the full line of BendPak products is available at bendpak.com.
