19
STEP 10
(Routing the Equalizer Cables)
1. Raise and lock each lift head approximately 28” above
the ground. (See Fig. 10.1)
Fig 10.1
XPR-9S
Equalizer Cable Routing
NOTE: WIDE conguration shown
MAKE SURE THAT THE SAFETY LOCKS ON EACH
POST ARE FULLY ENGAGED BEFORE ATTEMPTING TO
ROUTE EQUALIZER CABLES AND/OR HOSES.
CARRIAGES MUST BE EQUAL HEIGHT FROM
THE FLOOR BEFORE PROCEEDING.
WHEN THE CABLE ADJUSTING NUTS BOTTOM OUT
ON THE THREADED END OF THE CABLE
CONNECTOR AND THERE IS STILL SLACK IN THE
CABLES, THE CABLES HAVE STRETCHED BEYOND
THE SAFE USEFUL LENGTH AND NEED TO BE
REPLACED WITH FACTORY APPROVED CABLE
ASSEMBLIES. DO NOT PLACE WASHERS, SPACERS
OR OTHER DEVICES TO “SHORTEN” THE EFFECTIVE
CABLE LENGTH AS DAMAGE TO THE LIFT OR
INJURY TO PERSONS MAY OCCUR.
THE EQUALIZER CABLE SHEAVES WILL NEED
TO BE REMOVED TO EASE THE ROUTING OF THE
EQUALIZER CABLES. BE SURE TO REINSTALL
ALL PINS, COVERS AND CLIPS OR SERIOUS DAMAGE
OR INJURY MAY OCCUR.
