BendPak XPR-9S User Manual

34
If the lift was provided with Lift Arm Foot Guards, install the shorter Foot Guard on the shorter
Arm Assembly and the longer Foot Guard on the longer Arm Assembly.
To install rmly squeeze the ends of the Foot Guard inwards and insert the ends underneath
the bent ends of the arm support. Release to allow the Foot Guard to spring into place.
Check to be sure that Foot Guard is rmly in place.
Repeat this step for each Arm Assembly Foot Guard.
Arm Support
