BendPak XR-12000 User Manual

4
CLEARANCES
XR-12000
LIFT HEIGHT CLEARANCE NOTE: There must be a 1” MIN distance from top of the loaded vehicle to the
nearest obstruction when the lift is in a raised position.
XR-12000A
7627 OVERALL LENGTH
300
1
2
"
2560
TO NEAREST BAY
OR OBSTRUCTION
101"
1834
TO NEAREST BAY
OR OBSTRUCTION
72"
305
MIN
12"
6710 CLEARANCE TO FIT RAMPS IN STORAGE CONFIGURATION
264"
LIFT HEIGHT CLEARANCE NOTE: There must be a 1” MIN distance from top of the loaded vehicle to
nearest obstruction when the lift is in a raised position.
