When removing the lift from shipping angles, pay close attention as the ramps can slide and can cause injury. Prior
to removing the bolts make sure the ramps are held securely by a fork lift or some other heavy lifting device.
PARTS INVENTORY
Be sure to take a complete inventory of parts prior to beginning installation.
Description Qty
Power Unit Console 1
Left Ramp Assembly 1
Right Ramp Assembly 1
Drive-Up Ramps 2
Alignment Turnplate (XR-12000A only) 2
Work Step 2
Parts Box (Packing List Enclosed) 1
Parts Bag (Packaged in Part Box) 1
Power Unit
Console
Drive-Up
Ramps
Work Step
Left Ramp
Assembly
Right Ramp
Assembly
Alignment
Turnplates
*Note: For reference only. Not assembly instruction
