3000 Series Retail Operators Manual 108796 Rev C, 07/05
DEFAULT SETTINGS
The software program for each new dispenser shipped from the factory is preprogrammed with default settings in
some of the Menu Codes. Some menu codes must be changed immediately to make the dispenser operational in
your situation. See Initial Setup Sequence below. For your convenience, the default listings are noted below:
Menu Code
Description Default
0 Diagnostics
1 Money and Volume Totals
3 Manager Access 2218
4 Prices 0000
8 Decimal Location 0 = U.S.A.
9 No Flow Time Out - - - = Infinite Time
10 Slow Flow Amount 0.100 Volume Unit
11 Volume Allocation 9999 Volume Units
12 Prestart Time 2 seconds
15 Fleet Option 1 = Enabled
16 Unit Volume
17 Local Preset 0 = Disabled
18 Motor Delay 2 Seconds
21 Stand Alone Current Loop
22 Dispenser Address 0 = Program to set the dispenser address.
24 Preset Data Entry Digit Pointers Off
27 Meter Calibration 0.00
83 Cold Start
99 Volume Units Program to set the dispenser at gallon or liter operation.
Suggested Start Up Sequence
To program the dispensers memory for the first time, or following a RAM memory clear follow the menu codes in
the order that they appear in the “Initial Setup” sequence below. If not, the dispenser may not operate properly
because of default settings.
The menu codes are explained in the Operators Manual in numerical order.
Menu
Code No.
INITIAL SETUP
3
Manager Access Code
99
Unit of Measurement
4
Pricing
9
No Flow Time out
11
Volume Allocation for a sale at a pump
21
Current Loop, Stand Alone or RS485 mode
Menu
Code No.
REMAINING DISPENSER SETUP
8
Decimal Location - for other than U.S. standard
10
Slow Flow Amount - control for prepay sales
12
Precharge Time - for submerged pump
15
Fleet System - Interface compatibility
17
Local Preset - operation
18
Motor Delay - Self Contained Pumps
22
Dispenser Address
27
Meter Calibration—View Only
