3000 Series Retail Operators Manual 108796 Rev C, 07/05
DETERMINING THE MODEL NUMBER
Determine the model number of the dispenser from the serial plate located on the dispenser. Utilizing the chart below
determine the features of the dispenser to be installed. Understanding the features of the dispenser to be installed will
be helpful in understanding the proper installation of the dispenser.
How a Model for the 3800 Series Retail Dispensers is Made Up.
Note 2 - Motor -The hydraulic arrangement can be as follows-
Remote (submerged pump),
Suction with Standard 1 phase 115/230 v.a.c. 50/60 Hz,
Suction with 1 phase 115/230 v.a.c. 50/60 Hz with prepay valves,
Suction with 3 phase 380 v.a.c. 50 HZ,
Suction with 3 phase 380 v.a.c. with pre-pay valves
Pump Model Retail
Commercial Electronics Flow Rate # Products # Hoses
Motor
See Note 1
See Note 2
3811
X
210 Package All 1 1
3812
X
210 All 1 2
3822
X
210 All 2 2
3824
X
210 All 2 4
Note 1 - Flow Rate -
Standard - *23gpm (Remote) , 15 gpm (Self Contained)
Heavy Duty Suction - 24 gpm
Little Squirt - 35 gpm (nominal with one hose active, 40 gpm total with Master and Satellite in simultaneous flow ) with
1” valve (remote or suction)
Big Squirt - 35 gpm (nominal with one hose active, 60 gpm total with Master and Satellite in simultaneous flow) with 1-
1/2” valve (remote only)
*Flow rates are “nominal” (under ideal test conditions without accounting for system restrictions such as hanging hard-
ware. Actual flow rates will vary depending on conditions of installation.
To Next Page
