Bennett T75 Operation, Service, & Parts Manual Parts
22
Continued from previous page…
Item
Part No.
Description
Comment
33
N238301S
Rotor & Shaft Assembly 6-Blade
Standard 6 Blade Rotor
110245S
Rotor & Shaft Assembly 10-Blade
Side Inlet 10 Blade Rotor
34
110704
Rotor Blade
35
N481203
Bypass Valve Spring & Guide Assembly
Standard - Nickle
109415
Bypass Valve Spring & Guide Assembly
Standard – Nickel Plated
36
N106901
Pulley – Single Groove
100040
Pulley – Dual Groove
2.5” & 6” Hand Crank
39
A000301
Washer Lock
40
N190201
Insert – Air Separator Inlet
41
N160301
Insert, Filter Stop
42
N888301
Float Assembly Non-Reversing
43
A479902
Bolt
M8-1.25 X 25 mm (Use N840502 for Seal Wire Bolt)
45
A028101
Flat Washer 5/16”
47
100070
Strainer Assembly 70 Micron/200 Mesh
Standard Production
A311901
Filter Paper 35 Micron
N333501
Strainer 100 Micron 140 Mesh
Special – Used with Sack
N347301
Sack Filter 10 Micron
48
A199501
Key – Pulley
49
A263101
External Retaining Ring for ¾” Shaft
51
135N011001
Tube Elbow ¼-18 NPT
52
110211
Label Vertical PU
119517
Label Vertical PU E85
53
J325201
Spring Control Valve Short
Heavy Duty Delivery Pump 22 GPM
54
N905001
Spring, Filter
55
A323701
Shaft Seal Assembly without Plug
109711 Shaft Seal Kit Replacement – Includes (1) H597401 Seal Insertion
Tool – Plug, (1) A323701 Shaft Seal, (1) A247014 Square O-Ring)
56
110430
Pipe Plug
¼ -NPT
57
113022
Control Valve Assembly
Aluminum Body Version with Hard Coat - Includes 58 and 59
58
A320901
Pressure Relief Valve
59
111790
O-Ring #210
Also used with High Alcohol
SPARE PARTS LISTS
The dispenser quantity is recommended and may vary based on the options ordered for your dispenser.
Part No.
Description
Qty.
110704
Blade, Radius Corners, T75 PU
6
N481202
Bypass Valve Spring GRN & Guide Assembly
1
113022
Control Valve Assembly Aluminum with HC T75
1
109892
Float Atmospheric Assembly T75/T140 PU
1
KR044102
Kit Check Valve T75 After PU Code “5V”
1
KR042001S
Rotor Replacement Kit (Standard Delivery)
1
A323702
Shaft Seal Assembly with Plug
1
A323701
Shaft Seal Assembly without Plug
1
100070
Strainer Assembly 70 Micron/200 Mesh T75
1
KR042002
Kit Rotor Replacement –Includes #8, 55, 4, (2) 32, 33, (6) 34
1
