Bennett T75 Operation, Service, & Parts Manual Product Introduction
7
PUMP CURVES – U.S. M ARKET
PUMP CURVE – E UROPEA N MARKET
T-75 Pump (3/4 hp) Performance
U.S. Market
0
5
10
15
20
25
30
35
0 5 10 15 20 25
Flow Rate (gpm)
Pump Pressure (psi)
Pump Speed
700 rpm
Test
Conditions:
1. Tested on Stoddard Solvent
* 30 SSU Viscosity
* 0.78 Specific Gravity
2. 12 inches Hg operating vacuum
3. Fixed bypass cover
FIGURE 2
FIGURE 3
