Benning PV 3 - Data Management and Connectivity; Memory Operations and SUN 2 Radio Connection

01/ 2019 BENNING PV 3
19

number H. The symbol “RECALL” G is displayed
1
. The storage location number H is shown on the
display
1
.
- Press the key
3
to go to the previous storage location.
- Press the key
2
to go to the next storage location.
8.3.3 Deleting the measured value memory
- To delete the entire measured value memory, press the key
2
and the key
3
.
8.3.4 Reading out the measured value memory via the USB interface
To read the measured values via the USB interface
5
, you must install a hardware driver and the
BENNING SOLAR Datalogger software on your PC once.
The latest versions are available for free download on the product page of the BENNING PV 3.
http://tms.benning.de/pv3
In order to download the measuring data from the BENNING PV 3, proceed as follows:
- Disconnect all measuring leads from the BENNING PV 3.
- Connect the BENNING PV 3 to your PC by means of the USB connecting cable.
- The hardware driver is installed automatically on a free COM port and confirms that the new hardware
can be used.
- The COM port used can be viewed by means of the Device Manager of your system.
- Start the “BENNING SOLAR Datalogger“ program, in the “Tools” menu click “Refresh Ports” and select
the corresponding COM port. Then, click “Download”.
- Press the key
4
at the BENNING PV 3 for approx. 2 seconds until the download is made and the
complete measured value memory will be read out.
- The measured values can be stored as (*.csv) or (*.txt) file.
- Click “Open” to open the measured series e. g. via a spreadsheet.
8.4 Radio connection to insolation / temperature measuring instrument BENNING SUN 2
The BENNING PV 3 is able to receive the measured values (insolation, PV module / ambient temperature
and date / time stamp) of the insolation and temperature measuring instrument BENNING SUN 2 (optional)
via radio connection.
For this purpose, the BENNING PV 3 has to be coupled with the BENNING SUN 2 once.
Typical radio range of the BENNING SUN 2 in open space: approx. 30 m
Buildings / metal structures or interfering signals can reduce the radio range.
8.4.1 Coupling with BENNING SUN 2
- Remove all electronic devices in direct vicinity.
- Switch the BENNING PV 3 and the BENNING SUN 2 off.
- Press and hold the two ON/OFF keys of the BENNING SUN 2.
- Press and hold simultaneously the key
2
and the key
3
of the BENNING PV 3.
- The BENNING SUN 2 sends a coupling signal with the individual serial number of the device.
- The BENNING PV 3 stores the signal for future radio connection and signals successful coupling via
an acoustic signal and by showing “connected” on the display. The coupling process only takes a few
seconds.
- The “W/m
2
” symbol is shown on the LC display
1
of the BENNING PV 3.
8.4.2 Decoupling from the BENNING SUN 2
- Remove all electronic devices in direct vicinity.
- Switch the BENNING PV 3 off.
- Press and hold the key
2
and the key
3
of the BENNING PV 3 for approx. 10 seconds.
- The BENNING PV 3 indicates the decoupling from the BENNING SUN 2 by means of an acoustic
signal and by clearing the LC display.
- On the LC display
1
of the BENNING PV 3, the “W/m
2
” symbol is hidden.
8.4.3 Activating / deactivating the radio transmission of the BENNING SUN 2
- Couple the BENNING PV 3 with the BENNING SUN 2.
