Serial communication control 49
SYS_MenuModeInq 8x 09 06 06
FF
y0 50 02 FF On
y0 50 03 FF Off
CAM_LR_ReverseInq 8x 09 04 61
FF
y0 50 02 FF On
y0 50 03 FF Off
CAM_PictureFlipInq 8x 09 04 66
FF
y0 50 02 FF On
y0 50 03 FF Off
CAM_ColorSaturationInq 8x 09 04 49
FF
y0 50 00 00 00 0p FF p: Color Gain
setting 0h (60%) to
Eh (130%)
CAM_IDInq 8x 09 04 22
FF
y0 50 0p FF p: Gamma ID
IR_ReceiveInq 8x 09 06 08
FF
y0 50 02 FF On
y0 50 03 FF Off
CAM_BrightnessInq 8x 09 04 A1
FF
y0 50 00 00 0p 0q FF pq: Brightness
Position
CAM_ContrastInq 8x 09 04 A2
FF
y0 50 00 00 0p 0q FF pq: Contrast
Position
CAM_FlipInq 8x 09 04 A4
FF
y0 50 00 FF Off
y0 50 01 FF Flip-H
y0 50 02 FF Flip-V
y0 50 03 FF Flip-HV
CAM_GammaInq 8x 09 04 5B
FF
y0 50 0p FF p: Gamma setting
CAM_VersionInq 8x 09 00 02
FF
y0 50 ab cd
mn pq rs tu vw FF
ab cd: vender ID
(0220)
mn pq : model ID
ST
rs tu: ARM Version
vw: reserve
Command Function Command packet Note
