Appendix 1 – Screw List / Torque
STANDARD SCREW TORQUE SPEC.
ITEM P/N DESCRIPTION
MOUNTING
MATERIAL
TORQUE
(KG-CM)
HOLE SIZE
(MM)
Screw
Head
1
8F.205B4.019 SCRW MACH HEX #4-40*0.3" N
Metal;
D-SUB;DVI
Connector
5.0±0.6
5.0±0.6 #4-40
2
8F.5A224.6R0 SCRW MACH FLATM3*0.5P*6L ZN
Metal
Metal to metal
Plastic to metal
Side mount: 3±0.6
Other: 4±0.6
M3*0.5 #2
3
8F.EA324.6R0 SCRW TAP FH M3*6L ZN Metal
None tread： 8∼10
Have tread: 6∼8
Φ2.68±0.03 #2
4
8F.5A356.8R0 SCRW MACH FH M4*8L B-ZN NYL
Metal
Metal to metal
Plastic to metal
9.0±1.0 M4*0.7 #2
5
6K.L8810.001
ASSY SCREW M4*8L FP726A NLK
ISU
(8F.5A456.8R0+4B.L7212.001)
Metal
Metal to metal
Plastic to metal
9.0±1.0 M4*0.7 #2
6
8F.00273.6R0
SCRW TAP PH F/10WSH M3*6L C-
ZN
Metal
Metal to metal
Plastic to metal
PCB to metal
None tread： 8∼10
Have tread: 6∼8
Aluminum: 4~5
Æ2.68±0.03 #2
7
8F.VZ524.6R0
SCRW TAP FLAT+EXT M3*6L C-
ZN
Metal
Metal to metal
None tread： 8∼10
Have tread: 6∼8
Aluminum: 4~5
Æ2.68±0.03 #2
8
8F.00518.100 SCRW TAP W/FL M3*10L(S3.8)ZN
Metal
Metal to metal
Plastic to metal
SPEAKER to
metal
None tread：8∼10
Have tread: 6∼8
Aluminum: 4~5
Æ2.68±0.03 #2
9
8F.00003.143 SCRW TAP PAN #4-40*3/8
Aluminum
(Heatsink)
3.3±0.3 Φ2.6±0.03 #2
10
8F.VG234.6R0 SCRW TAP PH W/F M3*6 TP-S ZN
Aluminum
(Heatsink)
None tread： 8∼10
Have tread: 6∼8
Aluminum: 4~5
Φ2.68±0.03 #2
11
8F.VZ526.6R0
SCRW TAP FLAT+EXT M4*6L ZN-
W
Metal
Metal to metal
10±1.0 M4*0.7 #2
12
8F.HA334.8R0
SCRW TAP FPHM3*6(6/1)TP-S B-
ZN
Metal
Metal to metal
Plastic to metal
6~8 Φ2.68±0.03 #2
13
8F.5A456.8R0
SCRW MACH FLAT M4*8L C-ZN
NYLO
Metal
Metal to metal
Plastic to metal
9.0±1.0 M4*0.7 #2
14
8F.WA324.6R0 SCRW TAP CAP M3*1.34P*6L B-NI
Metal
Metal to metal
Plastic to metal
5.0±1.0 Φ2.35±0.05 #2
15
8F.XA324.5R0 SCRW TAP M3*5L B-ZB
Metal
Metal to Plastic
6~8 2.85~2.95 #2
16
8F.1A526.5R0 SCRW MACH PAN M4*5L NI
Metal
Metal to metal
Plastic to metal
8~10 M4*0.7P #2
