8
limit sample
then pass!
Limit Sample: TBD
(2) If it’s difficult to judge, then check 3.8.2
3.8.2
G
B
Defocus (Maximum) 3.5
3.0 3.0
Flare (Maximum) 4.0
4.0 4.0
3.9 Focus unbalance
Max. 50cm
3.10 Color Coordinate
(Confirm at PVT stage)
Color
hite
0.310±0.04 0.352±0.04
Red
0.625±0.04 0.367±0.04
Green
0.347±0.04 0.577±0.04
Blue
0.143±0.04 0.061±0.04
3.11 Color Uniformity
(Confirm at PVT stage)
Color
△uv
White
≦0.02
Red
≦0.02
Green
≦0.02
Blue
≦0.02
3.12 Color Gamut(Compare to NTSC) Typical 60%
3.13 Light Leakage in AA
△≦0.5 lux compared with center point @ full black pattern
within 60” (Diagonal at 2.264m).
This light-leakage is only described as the spot light with
obvious shape. The uniformity difference of black pattern is
not included.
3.14 Light Leakage out of AA
≦0.5 lux, @ full black pattern with 60“~80” (Diagonal at
2.264m)
(Except DMD Defect)
3.15 Ghost Ghost Contrast > (Confirm at
EVT2 stage)
3.16 Lens Shift Speed(sec)
(only for motorized len shift)
N.A.
3.17 Defect
(Color Band, Dark Corner,
Dark band)
Follow limited sample (When needed).
4.Lamp Specification
4.1 Lamp
SHP220W
4.2 Lamp Sync Type
DC Lamp
4.3 Lamp Flick Follow limited sample (When needed).
4.4 Lamp Power
Normal Mode
200W
ECO Mode
170W
5. Mechanical Specification
5.1 Color & Texture
specifications Refer to ID document for details
5.2 Physical Dimensions(Width X
Depth X Height)
287.3 x 232.6 x 114.4 mm
5.3 Gross Weight
≤2.3kg
5.4 Security Slot Kensington compatible slot 20Kg break away force
5.5 Lens Cover NA
5.6 Adjustment Feet
Fast adjustable foot in front, Adjustable foot in rear.
Front/ Rear foot Tilt: 0-6∘,Right/Left: +2.2∘/-0.5∘
5.7 Ceiling Mounting
Match BenQ’s ceiling mount required.
Use the same mounting as current shipping projectors.
5.8 Screws
ll color of screws should similar with the plastic color
which close it.
5.9 During PVT stage, limited sample
of color and texture should be
approved by BenQ industrial
designer and mechanical
N/A
