Positioning your projector18
MW533/TW533
The screen aspect ratio is 16:10 and the projected picture is 16:10
For example, if your projector is MW533/TW533 and using a 120-inch screen, the average
projection distance is 4407 mm and with a vertical offset of 61 mm.
If your measured projection distance is 5.0 m (5000 mm), the closest match in the
"Projection distance (mm)" column is 5509 mm. Looking across this row shows that a 150''
(about 4.0 m) screen is required.
Screen size Projection distance (mm) Ver tica l of fs et
(mm)Diagonal W
(mm)
H
(mm)
Min
distance
Average Max
distance
Inch mm (max.
zoom)
(min.
zoom)
35 889 754 471 1168 1285 1402 18
40 1016 862 538 1335 1469 1603 20
50 1270 1077 673 1669 1836 2003 25
60 1524 1292 808 2003 2203 2404 30
80 2032 1723 1077 2971 2938 3205 41
100 2540 2154 1346 3339 3672 4006 51
120 3048 2585 1615 4006 4407 4808 61
150 3810 3231 2019 5008 5509 6009 76
200 5080 4308 2692 6677 7345 8013 102
220 5588 4739 2962 7345 8079 8814 112
250 6350 5385 3365 8346 9181 10016 127
300 7620 6462 4039 10016 11017 12019 152
