BenQ SP830 - Timing Chart

Specifications 77
Timing chart
Supported timing for PC (including DVI-I) input
* denotes the timing may not support on using with the DVI-A or DVI-D input signal selected.
** denotes the timing may not support on using with the DVI-D input signal selected, or using
the splitting screen.
Resolution
Horizontal
Frequency
(kHz)
Vertical
Frequency
(Hz)
Pixel
Frequency
(MHz)
Mode
720 x 400 31.469 70.087 28.3221 720 x 400_70
640 x 480
31.469 59.940 25.175 VGA_60
37.861 72.809 31.500 VGA_72
37.500 75.000 31.500 VGA_75
43.269 85.008 36.000 VGA_85
800 x 600
37.879 60.317 40.000 SVGA_60
48.077 72.188 50.000 SVGA_72
46.875 75.000 49.500 SVGA_75
53.674 85.061 56.250 SVGA_85
1024 x 768
48.363 60.004 65.000 XGA_60
56.476 70.069 75.000 XGA_70
60.023 75.029 78.750 XGA_75
68.667 84.997 94.500 XGA_85
1280 x 768 47.776 59.87 79.5 WXGA_60
1280 x 1024
63.981 60.020 108.000 SXGA_60
79.976 75.025 135.000 SXGA_75
*91.146 *85.024 *157.500 *SXGA_85
1280 x 960
60.000 60.000 108 1280 x 960_60
85.938 85.002 148.500 1280 x 960_85
1440 x 900
55.935 59.887 106.500 WXGA+_60
70.635 74.984 136.750 WXGA+_75
*80.430 *84.842 *157.000 *WXGA+_85
1400 x 1050
65.317 59.978 121.750 SXGA+_60
*82.278 *74.867 *156.000 *SXGA+_75
1680 x 1050 65.290 59.954 146.250 Vista
**1600 x 1200 75.000 60.000 162.000 UXGA
VIDEO
(HDCP)
(Only for DVI-D
input)
15.75 60 13.51 480i
31.47 60 27 480p
15.63 50 13.5000 576i
31.25 50 27.000 576p
45.00 60 74.25 720p_60
37.50 50 74.25 720p_50
33.75 60 74.25 1035i
67.5 60 148.5 1035p
33.75 60 74.25 1080i_60
28.13 50 74.25 1080i_50
67.5 60 148.5 1080p
