BenQ ST4301K Installation Guide

6
CR
0x0D
Set-function listing
The PC can control the LCD Monitor for specific actions. The Set-Function command allows you to
control the LCD monitor behavior in a remote sit through the RS232 port. The
Set-Function packet format consists of 11 bytes.
Set-function description
Item
Description
Length
Total Bytes of Message excluding "CR"
Display ID
Identification for each of display
Display ID is “01” for LAN control
Command Type
Identify command type, "s"
(0x73h): Set Command
Command
Function command code: One byte ASCII code
Value [1~3]
Three bytes ASCII that defines the value
CR
0x0D
Set-function format
Send: (Command Type="s")
Name
Length
ID
Command
type
Command
Value1
Value2
Value3
CR
Byte count
1 Byte
2 Byte
1 Byte
1 Byte
1 Byte
1 Byte
1 Byte
1 Byte
Bytes
order
1
2~3
4
5
6
7
8
9
Reply: (Command Type="+" or "-")
Name
Length
ID
Command
type
CR
Byte count
1 Byte
2 Byte
1 Byte
1 Byte
Bytes
order
1
2~3
4
5
Example 1: Set Brightness as 76 for Display-02 and this command is valid.
Send (Hex Format)
Name
Length
ID
Command
type
Command
Value1
Value2
Value3
CR
