BenQ W1070 - Supported Timing for EDTV and HDTV (via Component Inputs); Supported Timing for Video and S-Video Inputs

59
Using the projector
• *Supported timing for 3D signal with Frame Sequential, Top-Bottom and Side-by-Side format.
**Supported timing for 3D signal with Frame Sequential format.
***Supported timing for 3D signal with Top-Bottom and Side-by-Side format.
• The timings showing above may not be supported due to EDID file and VGA graphic card limitations. It is
possible that some timings cannot be chosen.
*Supported timing for 3D signal with Frame Packing and Top-Bottom format.
**Supported timing for 3D signal with Frame Sequential format.
***Supported timing for 3D signal with Side-by-Side format.
1280 x 1024
SXGA_60*** 60.020 63.981 108.000
SXGA_75 75.025 79.976 135.000
SXGA_85 85.024 91.146 157.500
1280 x 960
1280 x 960_60*** 60.000 60.000 108
1280 x 960_85 85.002 85.938 148.500
1360 x 768 1360 x 768_60*** 60.015 47.712 85.500
1440 x 900 WXGA+_60*** 59.887 55.935 106.500
1400 x 1050 SXGA+_60*** 59.978 65.317 121.750
1600 x 1200 UXGA*** 60.000 75.000 162.000
1680 x1050 1680 x 105_60*** 59.954 65.290 146.250
640x480@67Hz MAC13 66.667 35.000 30.240
832x624@75Hz MAC16 74.546 49.722 57.280
1024x768@75Hz MAC19 75.020 60.241 80.000
1152x870@75Hz MAC21 75.06 68.68 100.00
Format Resolution Refresh rate (Hz) H. Freq. (KHz) Pixel Freq. (MHz) Aspect
480i** 720 (1440) x 480 59.94 15.73 27 16:9
480p 720 x 480 59.94 31.47 27 16:9
576i 720 (1440) x 576 50 15.63 27 16:9
576p 720 x 576 50 31.25 27 16:9
720/50p* 1280 x 720 50 37.5 74.25 16:9
720/60p* 1280 x 720 60 45.00 74.25 16:9
1080/24P* 1920 x 1080 24 27 74.25 16:9
1080/25P 1920 x 1080 25 28.13 74.25 16:9
1080/30P 1920 x 1080 30 33.75 74.25 16:9
1080/50i*** 1920 x 1080 50 28.13 74.25 16:9
1080/60i*** 1920 x 1080 60 33.75 74.25 16:9
1080/50P 1920 x 1080 50 56.25 148.5 16:9
1080/60P 1920 x 1080 60 67.5 148.5 16:9
