BenQ W1050 User Manual

Digital Projector
U
ser
Ma
n
ua
l
W1050/W1050S/HT1070A
V1.20

BenQ W1050 Specifications

General

Matrix type	DMD
Number of colors	1.073 billion colors
Native aspect ratio	16:9
Projection distance	- m
Projection technology	DLP
Contrast ratio (typical)	15000:1
Screen size compatibility	60 - 300 \
Projector native resolution	1080p (1920x1080)
Keystone correction, vertical	-40 - 40 °
Vertical synchronization (max)	0.12 kHz
Vertical synchronization (min)	0.023 kHz
Horizontal synchronization (max)	102 kHz
Horizontal synchronization (min)	15 kHz
Offset	107 %
Throw ratio	1.37 - 1.64:1
Focal length range	19 - 22.65 mm
Aperture range (F-F)	2.42 - 2.62
3D	-
Full HD	Yes
Supported video modes	480i, 480p, 576i, 576p, 720p, 1080i, 1080p
Analog signal format system	NTSC, PAL, SECAM
Supported graphics resolutions	640 x 480 (VGA), 1920 x 1200 (WUXGA)
DVI port	No
HDMI connector type	Full-size
Serial interface type	RS-232
USB 2.0 ports quantity	0
RMS rated power	2 W
Placement	Desktop, Ceiling
Product type	Standard throw projector
Product color	White
Market positioning	Home cinema
Cable lock slot type	Kensington
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	260 W
Power consumption (standby)	0.5 W
Power consumption (typical)	252 W
Power consumption (economy mode)	211 W
Lamp type	UHP
Lamp power	210 W
Lamps quantity	1 lamp(s)
Light source type	Lamp
Service life of light source	4500 h
Service life of light source (economic mode)	6000 h
Noise level	33 dB
Certification	CE, TÜV-Bauart
Noise level (economic mode)	31 dB
On Screen Display (OSD) languages	ARA, BUL, CHI (SIMPL), CHI (TR), CRO, CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HIN, HUN, IND, ITA, JPN, KOR, NOR, POL, POR, RUM, RUS, SWE, THA, TUR
Cables included	AC, VGA
Remote control type	IR
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	241.3 mm
Width	332.4 mm
Height	99 mm
Weight	2560 g

Summary

Important Safety Instructions

Introduction

Projector Features and Contents

Lists projector capabilities and items included in the package.

Projector Exterior View

Component Identification

Identifies external controls and ports on the projector's front and rear.

Controls and Functions

Projector Unit Controls

Explains the buttons and indicators on the projector unit itself.

Remote Control Operations

Basic Navigation and Picture Adjustments

Covers power, navigation, picture tuning, sound, and special feature buttons.

Remote Control Battery Replacement

Projector Positioning

Choosing Installation Location

Discusses selecting optimal placement based on room layout and screen.

Image Size and Distance Charts

Provides data for projecting specific image sizes and distances.

Connecting Sources

Connection Diagram and Overview

Illustrates various signal source connections and types.

Connecting Computers

Steps for connecting PCs via VGA or HDMI.

Connecting Video Devices

Guides for connecting HDMI and composite video sources.

Operation Basics

Starting Up and Adjusting the Projector

Steps for powering on, adjusting image angle, and auto-optimization.

Image Tuning and Keystone Correction

How to fine-tune size, clarity, and correct image distortion.

Using the OSD Menus

Guide to navigating and configuring projector settings via OSD.

Projector Security

Physical Security and Password Setup

Securing against theft and setting up password protection.

Password Management

Procedures for changing or recalling a forgotten password.

Switching Input Signals

How to select and cycle through available input sources.

Selecting Aspect Ratio

Adjusting the image width-to-height ratio for optimal display.

Image Optimization

Picture Modes and Fine-Tuning

Selecting preset modes and detailed controls for image quality.

Advanced Picture Controls

Setting Black Level, Gamma, Brilliant Color, Color Temperature, Noise Reduction, Film Mode.

Special Operation Modes

Using ECO BLANK and High Altitude Mode for specific conditions.

Sound and Control Settings

Audio Adjustments and Key Lock

Covers audio settings and locking projector controls.

Personalizing Menu Display

Customizing OSD language, type, position, and display time.

Shutting Down the Projector

Proper procedure for powering off the projector safely.

Menu System Overview

Basic Menu Options

Lists menu items and options for Basic menu types.

Menu Descriptions

Basic Menu (Without Signal)

Detailed explanations of menu items when no signal is present.

Projector Maintenance

Cleaning, Storage, and Transport

Guidelines for cleaning, storing, and transporting the projector.

Lamp Information and Life

Lamp Usage and Life Extension

Understanding lamp usage, life calculation, and extension methods.

Lamp Replacement Timing

Indicators and messages signaling the need to replace the projector lamp.

Replacing the Projector Lamp

Resetting the Lamp Timer

Procedure to reset the lamp timer after replacement.

Indicator Lights Status

Troubleshooting Common Issues

Power, Picture, and Alignment Problems

Solutions for no power, no picture, blurred images, and alignment.

Remote and Password Problems

Troubleshooting for remote control and password-related issues.

Technical Specifications

Key Specifications Overview

Summarizes optical, electrical, terminal, and environmental specifications.

Dimensions and Ceiling Mounting

Projector dimensions and detailed guide for ceiling installation.

Timing Charts

PC Input Signal Timing

Supported timing for VGA analog and HDMI digital PC inputs.

Video Input Signal Timing

Supported timing for various video input standards.

Warranty and Copyright

Limited Warranty Information

Information on product warranty coverage and terms.

Copyright and Legal Notices

Legal notices regarding publication rights, disclaimers, and regulatory names.
