BenQ W1050 - Connecting Sources; Connection Diagram and Overview

Connection18
Connection
When connecting a signal source to the projector, be sure to:
1. Turn all equipment off before making any connections.
2. Use the correct signal cables for each source.
3. Ensure the cables are firmly inserted.
1. VGA cable 2. VGA to DVI-A cable
3. USB Cable 4. HDMI cable
5. Audio cable (PC/RCA
jack)
6. Video cable
4
1
2
1
4
5
6
3
5
5
5
