Page #75 background imageLoading...
Page #75 background image
6 - Parameter Descriptions
75
I/O 00 Jump to Parameter
LCD Display
I/O: Jump Code
00 1
Description By changing the value of this parameter and pressing [ENTER], you can jump directly to any parameter within
that group.
I/O 01- 03 / P40 - 42 Digital Input Configuration
LCD / LED
Displays
I/O: DI 1 Config
01 Off
I/O: DI 2 Config
01 Off
I/O: DI 3 Config
01 Off
Range LCD LED Description
Off
OFF Off, Not Assigned, Input has no function. (Default DI 1, DI 2, DI3)
Stop
StOP Stop Command for 3-wire control.
Inching
inch Start the inching DC field application sequence.
Fault High
FH Fault High, Fault when input is asserted, 120V applied.
Fault Low
FL Fault Low, Fault when input is de-asserted, 0V applied.
Fault Reset
Fr Reset when input asserted, 120V applied.
FS1 Confirm
FS1 aux FS1 contact input to confirm FS1 contactor operation.
FS2 Confirm
FS2 aux FS2 contact input to confirm FS2 contactor operation.
Field Force
FF Switch to the field force current setting when energized.
Field Apply
FldA Allow DC field application. This input must energize after all other conditions
for field applications are met before the field will be applied.
Brake Disabl
bdlS Disable DC injection braking.
Brake Enable
bEn Enable DC injection braking.
Inline Cnfrm
InLn Inline contactor feedback.
Local/Remote
L-r Local/Remote control source, Selects whether the Local Source parameter or the
Remote Source parameter is the control source. Local Source is selected when
input is de-asserted, 0V applied. Remote Source selected when input asserted,
120V applied.
Description I/O parameters 1 - 3 configure which features are performed by the D1 to D3 terminals.
See Also Local Source (QST 04 / P37) parameter on Page 61.
Remote Source (QST 05 / P38) parameter on Page 61.
Incomplete Sequence Timer (QST 03 / P6) on Page 61.
OFF
OFF
OFF
