RediStart MX
2
- SEP Synchronous Controller User Manual
76
I/O 04 / P43 Digital Input Trip Time
LCD / LED
Displays
I/O: Din Trp Time
09 0.1 sec
Range 0.1 90.0 Seconds (Default: 0.1 Sec)
Description The Digital Input Trip Time parameter sets the length of time that the digital input must be high or low before a
trip occurs. This delay time only functions for fault high and fault low.
See Also Digital Input Configuration parameters on Page 75.
I/O 5 - 7 / P44 - 46 Relay Output Configuration
LCD / LED
Displays
I/O: R1 Config
05 Interlock FS
I/O: R2 Config
06 FS1
I/O: R3 Config
07 Running
Range LCD LED Description
Off
OFF
Off, Not Assigned. May be controlled over Modbus
Fault FS
FLFS
Faulted – Fail Safe operation. Energized when no faults present,de-energized
when faulted.
Fault NFS
FLnF
Faulted– Non Fail Safe operation. Energized when faulted.
Interlock FS
SIFS
Interlock relay, fail safe operation. This relay will energize when the controller is
ready for a start command. The interlock relay must be used to interlock the
stator controller. (Default R1)
Interlock NFS
SInF
Interlock relay, non fail safe operation. This relay will be energized when the
controller is not ready for a start command. The interlock relay must be used to
interlock the stator controller.
Running
run Motor is running. (Default R3)
Synced
SYnc
The controller has synchronized the motor.
Inching
inch
Controller is in inching mode.
Inch UTS
iutS
Controller is in inching mode and the inching UTS timer has expired.
Alarm
AL
Alarm, any alarm condition present.
Ready
rdYr
Ready, controller ready for start command.
Locked Out
LOC
Locked Out.
Overcurrent
OC
Overcurrent Alarm, overcurrent condition detected.
Undercurrent
UC
Undercurrent Alarm, undercurrent condition detected.
Shunt FS
ShFS
Shunt Trip Relay – Fail Safe operation, energized when no shunt trip fault present,
de-energized on shunt trip fault.
Shunt NFS
ShnF
Shunt Trip Relay – Non Fail Safe operation, de-energized when no shunt trip fault
present, energized on shunt trip fault.
FS1
FS1
Used to control a field application contactor. (Default R2)
FS2
FS2
Used to control a field discharge resistor contactor.
