Bentone
General
No Parameter Actuator controlled
201 Burner operating mode (fuel train, modulating / multistage, actuators, etc.) Air Fuel
-- = undefined (delete curves) • •
1 = gas modulating (G mod) • •
2 = gas modulating with pilot valve (Gp1 mod) • •
3 = gas modulating with pilot valve (Gp2 mod) • •
4 = oil modulating (Lo mod) • •
5 = oil 2-stage (Lo 2 stage) • -
6 = oil 3-stage (Lo 3 stage) • -
7 = gas modulating (G mod pneu) • -
8 = gas modulating (Gp1 mod pneu) • -
9 = gas modulating (Gp2 mod pneu) • -
10 = oil modulating with gas pilot (LoGp mod) • •
11 = oil 2-stage with gas pilot (LoGp 2-stage) • -
12 = oil modulating with 2 fuel valves (Lo mod 2V) • •
13 = oil modulating with gas pilot and 2 fuel valves (LoGp mod 2V) • •
14 = gas modulating (G mod pneu, 0 active) - -
15 = gas modulating with pilot (Gp1 mod pneu, 0 active) - -
16 = gas modulating with pilot (Gp2 mod pneu, 0 active) - -
17 = oil 2-stage (Lo 2-stage, 0 active) - -
18 = oil 3-stage (Lo 3-stage, 0 active) - -
19 = gas modulating only when firing on gas (G mod fuel active) - •
20 = gas modulating with pilot only when firing on gas (Gp1 mod fuel active) - •
21 = gas modulating with pilot only when firing on gas (Gp2 mod fuel active) - •
22 = oil modulating only when firing on oil (Lo mod fuel active) - •
!
Ensure that the fuel train is correctly set in compliance with the type of burner used.
