set the parameters as follows: compare more = 0 / limit 1 = IN00 / limit 2 = SP00 / limit const = 30
23: limit 1
(value range OFF, SP00 to CH19)
Selects the process value used as "limit 1" in the formula. This can be a setpoint, an actual temperature, a
channel (loop) output or "OFF" to insert "0" in the formula. For detailed explanation including an example refer
to "compare mode"
24: limit 2
(value range OFF, SP00 to CH19)
Selects the process value used as "limit 2" in the formula. This can be a setpoint, an actual temperature, a
channel (loop) output or "OFF" to insert "0" in the formula. For detailed explanation including an example refer
to "compare mode"
25: limit const
(value range -9999 to 9999)
The constant value used as "limit const" in the formula. For detailed explanation including an example refer to
"compare mode"
26: output on IDLE
(value range 0 to 2)
Defines the state of the digital output when the controller is IDLE: 0 = same as during programme run / 1 = OFF
/ 2 = ON
27: output on ERR
(value range 0 to 2)
Defines the state of the digital output when the controller enters a system error: 0 = same as during
programme run / 1 = OFF / 2 = ON
following parameters apply on selection PRC only:
32: process mode
(value range 0 to 18)
Selects the process state the digital output is indicating: 0=programme run (also ON during segment 0 and at
the end of the firing) / 1=programme run (also ON during segment 0) / 2=programme run / 3=end of the firing /
4=any channel error / 5=programme HOLD / 6=OFF / 7=ON / 10/11/12=mixer in air
excess/stochiometric/cooling mode / 13=programme continues after power breakdown / 14=do0.6 and not
do0.7 / 15=do0.6 and do0.7 / 16=not do0.6 and do0.7 / 17=control channel off band / 18=programme
interrupted due to off band / 19=any monitored channel error / 20=final temperature matches in all monitored
channels / 21=any monitored channel in control range / 22=any monitored channel out of control range
following parameters apply on selection EVE only:
42: EVENT number
(value range 0 to 10)
Digital output works as programme EVENT number #. This number must fit the EVENT number specified in the
programme table
43: output on IDLE
(value range 0 to 1)
Defines the state of the digital output when the controller is IDLE: 0 = OFF / 1 = ON
44: output on ERR
(value range 0 to 1)
Defines the state of the digital output when the controller enters a system error: 0 = same as during
programme run / 1 = OFF / 2 = ON
following parameters apply on selection TAB only:
52: table dat.src
(value range TA00 to TA04)
Select the column number of the programme table the programme value is taken
.
