bentrup TC507 User Manual

9
value is respected as overrun (causing an error)
following parameters apply on selection T/C only:
08: thermocouple
(options S, R, K, J, B)
Select the IEC code of the thermocouple used
09: external CJC
(value range OFF, IN00 to IN03)
Could junction compensation temperature. Set to "OFF" for internal compensation (recommended). Make sure
that the proper compensating wire is used
following parameters apply on selection LIN only:
18: signal type
(options OFF, 0-20mV, 0-50mV, 0-5V, 0-10V, 0-20mA, 4-20mA, -500R2, -
500R3)
Type of input signal. Set this parameter to fit the signal of the device connected to the physical input. Note:
Adapt the jumper settings of the physical input accordingly (done automatically on some devices)
19: val.@zeropoint
(value range -2000.0 to 2000.0)
Process value at lower reference of input value. Example: A pressure transducer supplying 4 to 20mA at -250 to
+250 Pa. Set this parameter to "-250" since this is the process value at the lower reference of 4mA
20: val.@fullscale
(value range -2000.0 to 2000.0)
Process value at upper reference of input value. Example: A pressure transducer supplying 4 to 20mA at -250 to
+250 Pa. Set this parameter to "250" since this is the process value at the upper reference of 20mA
following parameters apply on selection ATMS only:
28: temp. source
(value range IN00 to IN03)
Selects the process value representing the temperature of the atmosphere sensor. The temperature is required
for the calculation of the oxygen
29: min. CO temp
(value range 600 to 1800)
Minimum temperature in centigrade Kelvin required for carbonmonoxyde calculation. A minimum
temperature of 900°C (1273°K) is recommended for reliable calculation
30: press.source
(value range OFF, IN00 to IN03)
Selects the process value representing the over pressure of the reference air. This is used to supervise the
referece air for the oxygen probe. Set to "OFF" if not used
31: min. pressure
(value range 0 to 250)
Minimum pressure limit of reference air. Oxygen process value is set to "INVALID" if reference over pressure
falls below this limit
32: type of gas
(options NATGAS, PROPAN, BUTHAN)
Kind of the gas used. This selection is only used for calculating carbonmonoxyde
following parameters apply on selection RES only:
38: resist.type
(options PT100)
Kind of the resistance sensor used
39: signal type
(options -500R2, -500R3)
Type of input signal. Set this parameter to fit the signal of the device connected to the physical input. Note:
Adapt the jumper settings of the physical input accordingly (done automatically on some devices)
.
