bentrup TC507 - Programme Table Setup

15
.
Table 6: programme table
The programme table determines the parameters and the sequence to be entered for each programme
segment. The first programme parameter is always a time followed by a temperature. Depending on the
application the following programme segment parameters could be for instance offset temperatures (for
multizone kilns), programme events etc. The parameter sequence after the 1st temperature is variable;
however, keeping all programme EVENTs togather saves programme memory
.
00: value type
(options END, TIME, VAL-L, ---, VAL-S, EVENT, ATMS)
Select the kind of value in each column of the programme table:
TIME: The very first column of the programme table holds the segment time
VAL-L: Programme value in the range of -10000 to 10000. Typically used for any kind of absolute value (like kiln
temperature etc.)
---: selection not used
VAL-S: Programme value in the range of -127 to 128. Typically used for any kind of relative values (like offset
temperature for zones)
EVENT: EVENT value, ie. holds ON or OFF. When requiring multiple events defining them one after the other
saves programme memory
ATMS: Programme value to define an atmosphere
01: designator
(alphanumerical characters)
Used to give each programme table column an individual name (consisting of up to 3 alphanumeric letters)
following parameters apply on selection TIME only:
02: lower time lim
(value range -101 to 0)
Limits the value range entered as a time. Note that the values smaller than minus 2 enable the programme link
feature (-3 = allow linking to programme number 1, -4 = allow linking to programme number 2 etc.)
03: upper time lim
(value range 1 to 5999)
Upper limit when adjusting the time. The 1000 steps beyoind this limit stand for setting the gradient as
centigrade kelvin per period
following parameters apply on selection VAL-L only:
12: value unit
(options °C, °F, °K, dg, mV, mA, O2, CO, %, ev, mb, m³, m³h, kh, kwh, Pa, AT)
Specifies the unit of the programme table value
13: lower val. lim
(value range -9999 to 9999)
Lower limit of the programme table value. Used for instance to ensure the values entered by the user stay
within the operation limits of the kiln
14: upper val. lim
(value range -9999 to 9999)
Upper limit of the programme table value. Used for instance to ensure the values entered by the user stay
within the operation limits of the kiln
following parameters apply on selection --- only:
22: value unit
(options °C, °F, °K, dg, mV, mA, O2, CO, %, ev, mb, m³, m³h, kh, kwh, Pa, AT)
Specifies the unit of the programme table value
23: lower val. lim
(value range -9999 to 9999)
Lower limit of the programme table value. Used for instance to ensure the values entered by the user stay
within the operation limits of the kiln
