bentrup TC505/507 Configuration Table Version 1.12
Table 0: clock / calender
The controller uses its real time clock / calender for different purposes. It allows the automatic commencing of
programmes at predefined times as well the real time clock / calender is used to time stamp logged data and
events. When configuring the controller using bentrup WinConfig / WinControl the controller is automatically
updated with the PCs time / date information, Therefore manually changeing time / date is disabled
.
00: time (hours)
(value range 00 to 23)
current time (hours) of the real time clock
01: time (minutes)
(value range 00 to 59)
current time (minutes) of the real time clock
02: date (weekday)
(options MON, TUE, WED, THU, FRI, SAT, SUN)
current date (weekday) of the real time calendar
03: date (day)
(value range 01 to 31)
current date (day) of the real time calendar
04: date (month)
(options JAN, FEB, MAR, APR, MAY, JUN, JUL, AUG, SEP, OCT, NOV, DEC)
current date (month) of the real time calendar
05: date (year)
(value range 00 to 99)
current date (year) of the real time calendar
06: cfg.lock level
(value range 0 to 5)
reserved for future used
.
.
Table 1: misc. adjustments
The following miscalleneous adjustments determine general operation parameters of the controller
.
00: max. segments
(value range 5 to 98)
maximum number of segments per programme. Entering a smaller number increases the number of
programmes you can save in your controller. In most applications a maximum of 20 segments is suitable. Note:
After changing this value all programmes must be reentered because of the required reorganisation of the
controllers memory
01: ramp mode(s)
(options TIME, GRAD, BOTH)
Specifies how to define ramps:
TIME: Ramps entered as segment time
GRAD: Ramps entered as gradient (e.g. 200°C/h)
BOTH: Ramps can be entered as segment time as well as gradient
02: prg.end Temp
(value range 20 to 1800)
Defines the temperature the final ramp of the programme is finished. Parameter applies not to TC507
03: manual enable
(options OFF, ON)
