LED surgical lights, single and combination lights CHROMOPHARE
®
E 778, E 668, E 558
Appendix
110
15.3 Fuses, terminal voltages
15.3.1 Fuses
The following fuses must be supplied by the owner (all fuses:
inactive):
220 – 240 V 100 – 127 V Lighting
L, F1 L, F1
E 778 , E 668,
E 558
4 A 8 A
NOTE!
Fuses must be UL and IEC 60127 approved.
15.3.2 Terminal voltages
The terminal voltages cited in the following table must be
measured on the ceiling tube of CHROMOPHARE
®
surgical lights:
AC DC
21.5 V
(upstream filtering board)
24 (+ 1.5/- 0.3) V
