LED surgical lights, single and combination lights CHROMOPHARE
®
E 778, E 668, E 558
Connecting the electricity
73
11.3.2 ChromoVision
ECO camera system
Fig. 40: ECO connector
Connection/
Position
Connection
1 Y/C socket, video
