LED surgical lights, single and combination lights CHROMOPHARE
®
E 778, E 668, E 558
Technical Data
22
3 Technical Data
3.1 General information
The cardanic suspension of CHROMOPHARE
®
surgical lights is
available on a number of models.
Classic cardanic (A.C.) for normal ceiling heights.
Shortened classic cardanic (sA.C.) for medium-high to low
ceiling heights.
Flat cardanic (N.C.) for low ceiling heights.
Features in the following tables are marked "A.C.," "sA.C." or "N.C.,"
as appropriate.
The weights and maximum torques are specific to single lights
(including transformer and anchor plate), each with a 180-mm
ceiling tube and a 900-mm cantilever (Ø 125 mm).
CHROMOPHARE
®
E 778
Specifications Value
Unit
Weight incl. transformer 70
kg
Max. torque 531
Nm
Light head diameter 78
cm
Light emission surface area 3590
cm
2
Max. swivel radius 235,5
cm
Lowest position of light head (N.C.) 128
cm
Highest position of light head (N.C.) 228
cm
Lowest position of light head (sA.C.) 117
cm
Highest position of light head (sA.C.) 220
cm
Lowest position of light head (A.C.) 113
cm
Highest position of light head (A.C.) 220
cm
Clearance, single light (N.C.)
(with a 245.5-cm ceiling height)
200
cm
