LED surgical lights, single and combination lights CHROMOPHARE
®
E 778, E 668, E 558
Connectors
53
6.1.1 Sliding contacts
Fig. 17 Contact block
Part No. Description
78851 Contact block
Fig. 18 Sliding ring
Part No. Description
78849 Sliding ring
